Customize Wacom Display Settings

The Display Settings utility allows you to customize pen display settings.

Open Display Settings

1. Open Wacom Center.
2. Select your device in the Devices sidebar and then select Display Settings.
3. Click the Start button to proceed to the Wacom Display Settings application.
4. Select the Display to be customized from the drop-down menu.
5. Adjust the brightness and contrast as needed.
6. Select a Color Setting if you would like a particular type of display for your work. In the Color Setting menu:
• Select Color Temperature to make Color Temperature and Gamma options available.
• Select Color Space to make Color Space and Gamma options available.
• Select Custom Color and click Set button to open the Set Color dialog.
7. Click the Reset Color button to reset your color settings to factory defaults.
8. Click the Advanced button for additional settings for your display.
9. Click the Save button to save the current settings in the dialog.
10. Click the Revert button to undo any changes since the last Save, or since the display settings were started if a Save has not been done. Settings revert to that previous point.


The above screenshot is for descriptive purposes; it may not match your screen.
