Settings View

Settings View

You can view the current settings for the ExpressKey Remote keys, Touch Ring, and Touch Ring Mode indicators (LEDs) at any time.

  1. Open Wacom Center.
  2. Select EK Remote in the Devices sidebar.
  3. In the main content area, select ExpressKey settings. You will proceed to Wacom Tablet Properties.
  4. To view the ExpressKey Remote ExpressKey and Touch Ring key settings:
    • Set one of the ExpressKey Remote keys to Settings, and click that key to view all settings.
    • Click the key again to close the view.
    • Click the ExpressKey Properties... button or Touch Ring Properties... button at the bottom of the Settings screen to open the Wacom Tablet Properties to the ExpressKey Remote ExpressKeys tab, or to the ExpressKey Remote Touch Ring tab.
  5. To view the Touch Ring Mode settings:
    • Click the Touch Ring tab.
    • In the bottom left corner of the screen, make sure the Show touch ring setting checkbox is selected.
    • Press the Toggle (center) button of the Touch Ring to view the settings.
